Yamaha Z-SX-S 225-250HP 76Deg Lower Unit RH 30" Shaft Gearcase Trasmission Casing

IMPORTANT DISCLAIMER ABOUT LOWER UNIT COLOR:
The pictures shows lower unit painted Yamaha Silver/Gray color.  Manufacturing process was changed and lower unit will NOT come anylonger painted with Yamaha Silver/Gray top coat.
Lower unit come now with BLACK PAINT.
You can paint it to match

PLEASE SEND US A MESSAGE WITH YOUR ENGINE MODEL NUMBER TO MAKE SURE IT FITS YOUR ENGINE.

DESCRIPTION:
- Lower unit for most Yamaha Z/SX/S 225-250 HP
- RIGHT HAND lower unit.
- NEW aftermarket LOWER UNIT
- Includes 3 year warranty for recreational users. (Damaged Lower unit must be returned).
- Comes assembled ready to bolt on.  Just ad oil.

OTHER SPECIFICACION:
- Gear ratio 1.81:1
- Fits 30" midsections or 30" engines.
- 15 spline propeller shaft for 15 spline propellers.
- Driveshaft measurement: 32.5" from top of the drive shaft to the mounting surface (top of lower unit housing)
- Box measurements: 56"x29"x9" and weights 65 lbs.

APPLICATION SUMMARY:
- for 2 stroke engines only
- Z250TUR  2003 to 2005
- Z250TUR  2006 and UP
- SX250TUR 2000 to 2003
- SX225TUR 2000 to 2003
- S225TUR  1996 to 1999
- S250TUR  1996 to 1999
- 250TUR 1991 to 1995
- 225TUR 1995

APPLICATION LIST:
Z250TURD
Z250TURC
SX225TURB
SX250TURB
Z250TURB
SX225TURA
SX250TURA
SX225TURZ
SX250TURZ
SX225TURY
SX250TURY
S225TURX
S250TURX
S225TURW
S250TURW
S225TURV
S250TURV
S225TURU
S250TURU
225TURT
250TURT
250TURS
250TURR
250TURQ
250TURP

10% RESTOCKING FEE IN CASE OF RETURN on open boxes.
PLEASE SEND US YOUR ENGINE MODEL NUMBER TO MAKE SURE IT FITS YOUR ENGINE
