Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker 7049 Boat Marine

• Combines switching and circuit protection into a single device*

• Clear, single lever operation

• "Trip Free" design cannot be held "ON" during fault current condition

• Waterproof

• Recessed mounting holes for clean appearance

• Large Clearance around terminal studs accecpt heavy gauge wire lugs

• Robust 5/16 M8 terminals provide high torque connections

• Large lever with vertical/horizontal orientation provides indication of trip status

• Ignition protected Safe for installation aboard gasoline powered boats

• Interrupt Rating 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC

• Maximum Voltage Rating 48 Volts DC

• Operating Temperature Range -40xC to 85xC

• Circuit Breaker Type Thermally responsive bi-metal blade

• Circuit Breaker Class Type III switchable/manual reset trip free

• Terminal Stud Size 5/16"-18

• Terminal Stud Torque 75 in-lb

• Mounting Holes Accept #10 (M5) Screw

• Weight Lb (Kg) 0.50 (0.23)

• Case Material Thermoset Polyester
