SeaStar Baystar Hydraulic Steering Cylinder HC4645-3 Front Mount Mercury Honda
$616.99
Product Description
BRAND: SeaStar Solutions
DESCRIPTION:
- SeaStar Solutions HC4645H BayStar Compact Hydraulic Steering Cylinder, Outboard Engines.
- This balanced cylinder features a compact design that fits most splashwells.
- BayStar allows you to install all of the safety, reliability and comfort of hydraulic steering onto your boats rated up to MAX. 150HP.
- Combine this with the superior design, rigid ISO quality control, the finest materials and precision manufacturing-BayStar continues the tradition bringing comfort and safety to boating.
FEATURES:
- Balanced cylinder, featuring a compact design that fits most splash wells.
- Baystar provides hydraulic steering performance for the lower horsepower range.
- Ease of installation - can be fitted with the motor already hung on the transform
- Balanced cylinder for even turns lock to lock
- Universal Design - will fit most engines with the removal of 2 bolts
- High levels of steering efficiency - do drag links or off-sets
- Stainless steel and anodized aluminum construction
DIMENSIONS
- Stroke 8" (203mm)
- Shaft Diameter .63" (16.0mm)
SEAL REPARI KIT
- HP4600
APPLICATION NOTE:
- See last picture.
- MAXIMUM 150 HP Outboard Engines
- Mercury Optimax should use SeaStar cylinders. Not recommended for use on high performance engines.
APPLICATION DETAILS:
FORCE
- 1985-DATE 90-150 HP
HONDA
- 1992-DATE 30-90 HP
- 2001-DATE 150 HP (High performance 150HP engines should use SeaStar)
- 2003-DATE BF135 HP
JOHNSON / EVINRUDE
- 1991-DATE 40-150 HP
- 1997-DATE 75-150 HP FICHT (High performance 150HP engines should use SeaStar)
MERCURY
- 1984-DATE 75-150 HP (High performance 150HP engines should use SeaStar)
NISSAN
- 1990-DATE 120-140 HP
SUZUKI
- 1986-DATE 150 HP (High performance 150HP engines should use SeaStar)
- 1987-2002 115-140 HP (Requires Spacer Kit Part No. HO5090)
- 1990-2000 90-100 HP
- 1998-DATE 40-70 4-Stroke (Requires Spacer Kit Part No. HO5090)
TOHATSU
- 1990-DATE 40-140 HP
YAMAHA
- 1998-DATE 40-50 HP (Engine clamp brackets must be cut or ground,and the engine through bolted onto the transom, or interference will occur, restricting engine trim and tilt)
- 1998-DATE 60 HP (Steering hook Yamaha Part No. 63D-48511-00-4D must be installed)
- 1986-DATE 70-90 HP (Requires Spacer Kit Part No. HO5090)
- 1997-DATE 80-150 HP 4-Stroke
Manufacturer PN: HC4645H
Internal Code: 800616
Returns IN NEW ITEMS accepted in 14 days"""ONLY""" if they have NOT being installed and are in similar condition as when they were shipped. If you missed parts of the item, item CANNOT be returned.
DESCRIPTION:
- SeaStar Solutions HC4645H BayStar Compact Hydraulic Steering Cylinder, Outboard Engines.
- This balanced cylinder features a compact design that fits most splashwells.
- BayStar allows you to install all of the safety, reliability and comfort of hydraulic steering onto your boats rated up to MAX. 150HP.
- Combine this with the superior design, rigid ISO quality control, the finest materials and precision manufacturing-BayStar continues the tradition bringing comfort and safety to boating.
FEATURES:
- Balanced cylinder, featuring a compact design that fits most splash wells.
- Baystar provides hydraulic steering performance for the lower horsepower range.
- Ease of installation - can be fitted with the motor already hung on the transform
- Balanced cylinder for even turns lock to lock
- Universal Design - will fit most engines with the removal of 2 bolts
- High levels of steering efficiency - do drag links or off-sets
- Stainless steel and anodized aluminum construction
DIMENSIONS
- Stroke 8" (203mm)
- Shaft Diameter .63" (16.0mm)
SEAL REPARI KIT
- HP4600
APPLICATION NOTE:
- See last picture.
- MAXIMUM 150 HP Outboard Engines
- Mercury Optimax should use SeaStar cylinders. Not recommended for use on high performance engines.
APPLICATION DETAILS:
FORCE
- 1985-DATE 90-150 HP
HONDA
- 1992-DATE 30-90 HP
- 2001-DATE 150 HP (High performance 150HP engines should use SeaStar)
- 2003-DATE BF135 HP
JOHNSON / EVINRUDE
- 1991-DATE 40-150 HP
- 1997-DATE 75-150 HP FICHT (High performance 150HP engines should use SeaStar)
MERCURY
- 1984-DATE 75-150 HP (High performance 150HP engines should use SeaStar)
NISSAN
- 1990-DATE 120-140 HP
SUZUKI
- 1986-DATE 150 HP (High performance 150HP engines should use SeaStar)
- 1987-2002 115-140 HP (Requires Spacer Kit Part No. HO5090)
- 1990-2000 90-100 HP
- 1998-DATE 40-70 4-Stroke (Requires Spacer Kit Part No. HO5090)
TOHATSU
- 1990-DATE 40-140 HP
YAMAHA
- 1998-DATE 40-50 HP (Engine clamp brackets must be cut or ground,and the engine through bolted onto the transom, or interference will occur, restricting engine trim and tilt)
- 1998-DATE 60 HP (Steering hook Yamaha Part No. 63D-48511-00-4D must be installed)
- 1986-DATE 70-90 HP (Requires Spacer Kit Part No. HO5090)
- 1997-DATE 80-150 HP 4-Stroke
Manufacturer PN: HC4645H
Internal Code: 800616
Returns IN NEW ITEMS accepted in 14 days"""ONLY""" if they have NOT being installed and are in similar condition as when they were shipped. If you missed parts of the item, item CANNOT be returned.
