Bennett Hydraulic-to-Lenco Electric 12V Retrofit Kit 15064-001 for Trim Tab MD

BRAND: Lenco

DESCRIPTION: Bennett Hydraulic-to-Lenco Electric Conversion & Performance Upgrade Kit

IMPORTANT NOTES:
1) Lenco Marine's RetroFit Kit is designed as a direct replacement for the Bennett hydraulic power unit (HPU) on systems using Bennett's 4-ring standard trim tab actuators.
2) Bennett Joystick Control cannot be retrofitted to the Lenco actuators, but will retrofit both Bennett rocker switches.
3) You may also want to consider replacing your Trim Tab switch at this time.

Fits: Any boat with Bennet Hydraulic trim tabs


How to Convert From Hydraulic to Electric - 12 and 24-Volt Actuators

- The simple Bennett RetroFit Kits include everything necessary to upgrade your current boat without drilling or filling.
- You simply discard the hydraulic pump unit and the two Bennett cylinders.
- Connect the new actuator wiring to the existing harness (jumper wires are included for attaching to current switch).
- Complete installation instructions are included.


Just 4 simple steps:

1. Remove Bennett actuators and install Lenco upper mounting brackets on transom.
2. Feed Lenco wires through holes in brackets and through existing oil line holes in transom.
3. Mount Lenco actuators on to new upper brackets and existing Bennett lower brackets.
4. Connect Lenco Actuator wires to existing harness.

INFORMATION ABOUT THE RETROFIT KIT.
Now you don’t have to buy a new boat or an entire new set of trim tabs to get all the advantages of the latest in trim tab technology. Lenco’s highperformance instant response actuators are now available to retro fit any boat equipped with the standard length Bennett hydraulic cylinders.

Features include:
- Upgrade to our instant response electric actuators
- Improved boat performance
- Eliminate messy hydraulic pump unit
- Use your existing Bennett trim blades
- No new holes to drill
- Retrofits other hydraulic systems with minor modifications
- No more replacing unreliable hydraulic pump units

Specifications:

• Trim Tab Kit: Bennett Retrofit
• Switch Kit: Sold Separately
• Class: Fuel Efficient
• Compliance: CE Certified
• Compatibility: Any Boat
