Ezy-Glide Model 840 Stik II Stick Steering KIT 11' Cable Jet 90 HP Outboard 70HP

BRAND: Ezy-Glide

DESCRIPTION:
- Ezy-Glide Stick Steering
- Model 840, Stik II
- PORT MOUNT ONLY

FROM THE MANUFACTURER:
- The Classic Ezy-Stik Steering System! Ezy-Stik II Model 840 is the standard for convenience.
- The slower ratio of the Ezy-Stik II provides the added mechanical advantage needed for higher horsepower as well as 4-stroke engines.
- The 840 has a manufacturer’s maximum horsepower rating of 70hp/90hp Jet.
- Ezy-Glide only recommends 80 Below Action Lube or 80 Below Sporting Oil for Ezy-Stik lubrication

FEATURES:
- A mechanical steering system designed so the operator may be positioned in the front for better visibility and convenience. - A one piece stainless steel drive spool along with a durable high impact housing provide a superior single lever steering platform for today’s fisherman.
- The slower ratio provides the added mechanical advantage needed for higher horsepower as well as 4 stroke engines.
- Total handle travel: 58”/206 Degree.
- Ratio: 6.4/1.

SPECIFICATIONS:
- Total lever movement: 58 inches/206 degrees
- Steering ratio: 6.4/1
- Housing dimensions: approximately 6” x 6”
- Lever length: 16” (20” lever option also available at additional cost)

APPLICATION:
- Outboard engines not to exceed 70 H.P.
- Jet Drives not to exceed 90 H.P.

Manufacturer PN: 840-1100
Internal Code: 336239

NO RETURNS:
- Buyers install cables, pull them, and then return them with scratches in the jacket and damage boxes.
- No returns on OPEN box cables. If Box is unopended we can ONLY exchange.
- make sure you are buying the correct cable size.
