Product Description
BRAND: Blue Sea Systems
DESCRIPTION:
8086 AC 3 Sources +12 Positions/DC Main +19 Position Toggle Circuit Breaker Panel White SwitchesFeatures:Includes set of 30 common AC and 30 common DC labelsAll AC and DC buses installed fully pre-wiredLabel backlighting pre-installedAll LEDs installedMaximum panel Amperage100 Amperes DC50 Amperes ACAC Features:Two separate AC load groups with transfer switch to combine into one load groupSwitch allows Ammeter and Voltmeter to read either AC load groupReverse polarity indicators on both AC load groupsReady for installation of optional 4031 AC Isolation Cover9353 0-150 Volt AC Voltmeter9630 0-50 Amp AC AmmeterDC Features:100 Amp C-Series circuit breaker provides main circuit protection and switching for DC branch circuits8003 8-16 Volt DC Voltmeter8017 0-100 Amp DC AmmeterSpecifications:AC Positions: Source Selectors +12DC Positions: Main +19120 Volts AC12 Volts DC(3) 30A (1) 50A (6) 15A AC Circuit Breakers(1) 100A (13) 15A DC Circuit Breakers*Combined AC/DC panels require a AC Insulating Cover to meet ABYC StandardsWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Manufacturer Part Number: 8086
Internal Code: 14572
Brochure:
Instalation Guide:
Video:
Need more info?
Ask a question.
We answer questions quickly....
DESCRIPTION:
8086 AC 3 Sources +12 Positions/DC Main +19 Position Toggle Circuit Breaker Panel White SwitchesFeatures:Includes set of 30 common AC and 30 common DC labelsAll AC and DC buses installed fully pre-wiredLabel backlighting pre-installedAll LEDs installedMaximum panel Amperage100 Amperes DC50 Amperes ACAC Features:Two separate AC load groups with transfer switch to combine into one load groupSwitch allows Ammeter and Voltmeter to read either AC load groupReverse polarity indicators on both AC load groupsReady for installation of optional 4031 AC Isolation Cover9353 0-150 Volt AC Voltmeter9630 0-50 Amp AC AmmeterDC Features:100 Amp C-Series circuit breaker provides main circuit protection and switching for DC branch circuits8003 8-16 Volt DC Voltmeter8017 0-100 Amp DC AmmeterSpecifications:AC Positions: Source Selectors +12DC Positions: Main +19120 Volts AC12 Volts DC(3) 30A (1) 50A (6) 15A AC Circuit Breakers(1) 100A (13) 15A DC Circuit Breakers*Combined AC/DC panels require a AC Insulating Cover to meet ABYC StandardsWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Manufacturer Part Number: 8086
Internal Code: 14572
